Negative Oxygen Ion Monitoring System FT - FZ4: Precision Monitoring for Perfect Natural Oxygen Bars

Against the backdrop of a scenic area's commitment to creating a "natural oxygen bar," the Negative oxygen ion monitoring system FT-FZ4 has been introduced.

It can monitor the concentration of negative oxygen ions in different areas of the scenic area in real time. Taking into account various environmental parameters such as temperature, humidity, air pressure, PM2.5, and PM10, it forms a complete environmental data chain, providing abundant data for a comprehensive understanding of the air quality situation in the scenic area. It transmits the monitoring data to the cloud platform, WEB, or WeChat official account in real time through GPRS/4G and other means, making it convenient for the management personnel of the scenic area and tourists to view at any time and realizing data sharing.

This system adopts a modular structure design and is equipped with a professional installation bracket, resulting in low costs for later operation and maintenance. On-site, the data can be directly read through an LED screen, and an external LED screen display can be connected. It can clearly and intuitively display information such as the concentration of negative oxygen ions, temperature, and humidity, facilitating tourists and the management personnel of the scenic area to understand the environmental situation of the scenic area. Moreover, it can analyze and process the collected data, draw curves of the change in the concentration of negative oxygen ions over time, etc., providing a basis for the evaluation and research of the environmental quality of the scenic area.

The configuration is as follows:

Negative oxygen ion sensor: Adopting the cylindrical electrode suction measurement method, the measurement range is 0 to 100,000 ions/cm³, the resolution is 1 ion/cm³, the measurement error of the reading is ±10%, and the ion mobility is ≤±20%. It can accurately capture the changes in the concentration of negative oxygen ions in the air.

Meteorological environment monitoring equipment: It includes an atmospheric temperature and humidity sensor. The temperature measurement range is -40°C to 60°C, with an accuracy of ±0.3°C. The humidity measurement range is 0 to 100% RH, with an accuracy of ±3%. There is also a wind speed and direction sensor. The wind speed measurement range is 0 to 60m/s, with an accuracy of ±(0.3 + 0.03V)m/s. The wind direction measurement range is 0 to 360°, with an accuracy of ±3°. The atmospheric pressure sensor has a measurement range of 10 to 1100hpa, with an accuracy of ±0.3 hPa, enabling comprehensive monitoring of the meteorological environment elements in the scenic area.

Particulate matter monitoring equipment: It can monitor particulate matters such as PM2.5 and PM10. The measurement range is 25 to 500ug/m³, the resolution is 0.01mg/m³, and the accuracy is ±10%, effectively monitoring the content of particulate matters in the air quality of the scenic area.

Noise monitoring equipment: The measurement range is 30 to 130dB, the frequency is 31.5Hz to 8kHz, and the accuracy is ±1.5dB. It can monitor the noise situation in the scenic area in real time.

Data collection and transmission equipment: A data collector is configured. The environmental temperature ranges from -40°C to 75°C. The sampling frequency is 0.5s per time. The working power supply is 220VAC. It has a liquid crystal display. The power consumption of the whole machine is not more than 2W. The data storage capacity is 4M, and the storage capacity can reach 100,000 pieces of data. It has an RS485 port and can be connected to a PC or a laptop computer. It supports various communication methods such as GPRS/GSM/wifi/sms, and can transmit the monitoring data to the monitoring platform in real time.

LED display screen: The size is 2×1 meters, including the installation component bracket. It can clearly and intuitively display data such as the concentration of negative oxygen ions, temperature, and humidity, making it convenient for tourists and the management personnel of the scenic area to understand the environmental situation of the scenic area at any time.
